Carbon Steel JIS 10K WCB SUS304 Trim Flanged RF OS&Y BB 10K Swing Check Valve

Ask Lasest Price
Brand Name :	ANRY
Model Number :	Z41H
Certification :	API,CE,ISO
Price :	Negotiable
Payment Terms :	L/C, T/T
Supply Ability :	10000pcs/month
Delivery Time :	7 DAYS

Add to Cart

Product Details
Company Profile

Carbon Steel JIS 10K WCB SUS304 Trim Flanged RF OS&Y BB 10K Swing Check Valve

Swing Check Valve JIS10K/20K

OS&Y, Rising stem, Flexible Wedge

Bolted Bonnet,Threaded or welded seat ring

ASTM , A351 CF8, A351 CF8M,

A351 CF3, A351 CF3M,

Standards compliance

Design and Manufacture:

Face to face(end to end): JIS B2002

Flanged connection: JIS B2239

Test and inspection: API598,

Handwheel,Pneumatic/Electric

actuator operated are available.

Description:
A. Allowed Leakage rate: ≤ 0.1mm3/sec*size;
B. High temperature pre-painting, antirust and anti-corrosion process;
C. Caple of withstanding temperature of 300° C, continuous and 350° C short term exposure.
1) Size: 50A~800A;
2) Pressure class:150Lb~2500Lb;
3) Temperature: -29° C ~ 425° C;
4) Body/Bonnet: A216 WCB, Silver or Stainless Steel

Design Standard: APID,BS1868
Flanged Standard: ASME B16.5
Face to Face Standard: ASME B16.1
Inspection and testing Standard: API598

5) Suitable medium: Water, oil, vapor, gas;
6) Body material: WCB, WC1, WC5, WC6, WC9, C12, CF3, CF8, CF3M, CF8M;
7) CF8/SS304 disc, CF8 nuts;
